Stack Sampler

Monitoring of stacks and vents are requirement to ensure that emission of air pollutants are within the limit prescribed by regulatory authorities. By regular monitoring of emission one can establish that functioning and performance of installed control system are within the designed limits. Emission data also helps in improving performance of Air Pollution Control System energy saving and helps in optimizing process operation.

EI -106 has been developed to fulfill these requirements where user ease and emission monitoring regulations requirement have been given due consideration for reliable data generation.

Stack Gas Temp. : Up to 600 degree C A digital pyrometer and 1m Long thermocouple is provided

Thermocouple : Thermocouple is made up of SS 304 Casing, length of insertion: 1.0 m with 2 m long cable with suitable connector.

Monometer : Digital with 0-1300 mm of H2O Column.

Pitot Tube : S-Type pitot tube fabricated from SS 304, 1.0m length extendable to 2m, individual, calibrated at reference setup of Lata envirotech traceable to FCRI Palakkad

Particulate Sampling : SPM collection in thimble type filter (with pore size of 1.6μm with collection efficiency for 0.3μn particles 99.7%)

Gaseous Sampling : Collections of gases @ 0.3-3 lpm in chemicals kept in a set of 120 ml capacity borosilicate glass impingers

Rotameter : Plastic body rotameter with 2% FSD accuracy, 0-30 lpm for particulate and 0-3 Lpm for gases.

Sampling Probe : Made from SS 304 tube, 1.0m length extendable to 2.0m Filter Holder : Fabricated from SS 304 tube suitable to hold either cellulose filtration thimble (size 28 mm ID x 100 mm ling) or glass micro fiber thimble (size 19 mm ID x 90 mm long).

Nozzles : A set of 3 stainless steel nozzles of different diameter Digital Clock : 0-60 minutes, 1 second readout with start stop and reset functions.

Sampling Tray : 1 Nos. of 240 ml capacity and 2 Nos. of 120 ml capacity borosilicate glass Impingers. Accommodated in SS ice tray, placed on the rear side of instrument panel with a provision to keep ice.

Vacuum Pump : Vacuum Pump Mono block Rotary vane type oil filled, 0.5 HP, Single phase motor (230 V) with 40 lmp free flow capacity.
